ScanAfia XS Hospital Bed


ScanAfia XS Hospital Bed

Extremely low and easy to move

Main features:

1. Ergonomic working position thanks to impressive height adjustment range

2. High safe working load (SWL): 260 kg

3. Easy to manoeuvre thanks to its twin castors (optional)


About

The quality ScanAfia XS hospital bed is the safe choice for hospital wards. The bed has been designed for use by healthcare professionals in hospitals, healthcare centres and similar facilities, and it fulfils the requirements of the new EN 60601-2-52:2010 standard for medical beds.

Although it can take loads up to 260 kg (SWL), the ScanAfia XS hospital bed is still light and easy to manoeuvre, thanks to the optional choice of double castors. The design places emphasis on both ergonomic working and patient comfort and accessibility; its exceptionally low minimum height makes work easier for nurses and makes getting out of bed easier for patients. The back section slide mechanism also improves patient comfort. The bed also features an extremely broad Trendelenburg / Anti-Trendelenburg adjustment range.

The Range

ScanAfia XS-280/290 2-part bed section (205 X 80/90 cm), with electrical height and back section adjustment.

ScanAfia XS-480/490 4-part bed section (205 X 80/90 cm), with electrical height, back, thigh and calf section adjustment.

Our many years’ experience in designing and manufacturing hospital beds ensures that the ScanAfia XS provides a long service life with minimal need for maintenance.


Technical standard features:

  • Safe working load (SWL) 260 kg
  • Trendelenburg 12° / Anti-Trendelenburg 20° adjustment
  • Electrical height and back section adjustment with hand control (with models S-280 and S-290)
  • Electrical height, back, thigh and calf section adjustment with hand control (with models S-480 and S-490)
  • Epoxy-coated or chromium steel frame
  • Epoxy-coated or chromium bed-end at head section, plate available in standard colours: white, blue, yellow, light green, birch-colored and beech-colored
  • Brake lever at the foot-end (long metallic foot pedal) or individual brake pedals at the foot-end
  • Manual emergency lowering of back section
  • Back section slide
  • Lowest height starting from 32 cm
  • Height adjustment going straight up reduces the need for space
  • Ø125 central locking castors and direction wheel
  • Fixings for restraining belt
  • Bumper rollers
  • Built-in place for lifting pole and two IV poles
iphone white
TECHNICAL DATA
Total width (incl. siderails) 89,5 or 99,5 cm
Total length 215 cm
Height adjustment Min. 32 cm - max. 82 cm (depending on the castor size and type)
Recommended mattress size 205 x 78/88 x 13 cm
Total weight (without rails) 80 cm wide 108 kg, 90 cm wide 110 kg
Castors Ø125 centrally lockable wheels (Ø125 mm and Ø150 mm twin castors as an option)
Safe Working Load (SWL) 260 kg
Electrical system 24V
Trendelenburg/Anti-Trendelenburg 12°/ 20°
Back section adjustment 70°
Thigh section adjustment 30°
Calf section adjustment 11°
CE-marked Yes
Warranty 2 years
Country of Manufacture Finland
