Lojer Scandia SC440 Prime
Versatile surgical positioning with efficient electric adjustment
Scandia SC440 Prime is a versatile electric operating table for day and short-stay surgery. Its modular construction supports a wide range of surgical positions, while electric adjustment and programmable positions help the surgical team set up the table efficiently.
The functional frame design provides room for the surgical team and supports easy cleaning and maintenance. The table combines the functions required for surgical procedures with an excellent price-quality ratio.
Key benefits
What makes Scandia SC440 Prime different.
Versatile positioning for surgical procedures
The modular table-top supports a wide range of positions, including flex and reflex positions.
Faster adjustment between positions
Simultaneous movements of different sections are available when using pre-programmed or zero position.
Efficient working space around the table
The frame construction is designed to provide more room for the surgical team to operate.
Easy to clean and maintain
The clear frame structure supports cleaning and service access, helping maintain a high level of hygiene.
Excellent price-quality ratio
The table combines versatile functionality and high-quality construction with an excellent price-quality ratio.
Key features
- Versatile electric operating table for day and short-stay surgery
- Modular table-top construction for a wide range of surgical positions
- Flex and reflex positions
- Four programmable memory positions and zero position
- Simultaneous movement of different sections when using pre-programmed or zero position
- Hand control and integrated control panel on the column
- Four 125 mm central locking twin castors
- Easy-to-use manual wheel braking mechanism, also includes a directional wheel
- Battery-operated 24 VDC electrical system with 100-240 VAC, 50/60 Hz supply
- Functional frame construction designed to support cleaning and maintenance
- Optional 300 mm electric sliding top
- Optional X-ray cassette tunnel and cassette holder for the back and leg section
Models / Configurations
Scandia SC440 Prime is supplied as one operating-table platform with factory-installed configuration options selected when ordering. Six or seven section configurations available.
Scandia SC440 Prime
- Four programmable memory positions and zero position
- Hand control and integrated control panel on the column
- Optional electric sliding top: 300 mm
- Optional X-ray cassette tunnel and cassette holder for the back and leg section
- Optional foot control unit
Technical specifications
| Specification | Value |
|---|---|
| Total length | 2070 mm |
| Width including side rails | 622 mm |
| Mattress width | 550 mm |
| Total weight | 200 kg |
| Safe working load (SWL) | 250 kg |
| Lifting capacity | 454 kg |
| Height adjustment range | 595-1005 mm |
| Castors | Four 125 mm central locking twin castors |
| Head section | -58° … +37°, 135 mm |
| Back section | -10° … +70° |
| Leg section | -80° … +10° |
| Lateral tilt | 20° / 20° |
| Trendelenburg / anti-Trendelenburg | 30° / 20° |
| Slide (optional) | 300 mm |
| Flex / reflex | 220° / 120° |
| Electrical system | 24 VDC, battery operated 100-240 VAC, 50/60 Hz |
| Controls | Hand control and integrated control panel on the column |
| Memory positions | Four programmable positions |
| Warranty | 2 years |
| Manufacturer and country | Lojer / Finland |
| CE-marked | Yes |
Options and accessories
Factory-installed option
- Electric sliding top (300 mm)
- X-ray cassette tunnel + cassette holder (back and leg section)
