Lojer 4040X General Examination Table
Safe and versatile examination table
The 4040X general examination table is suitable for use in various healthcare facilities. Its exceptionally wide height adjustment range of 40–95 cm allows ergonomic working positions for the clinician, and the low minimum height means that both children and elderly patients can easily get onto the table.
Safety functions work in the background: the table detects a pinching situation, stops the movement and raises to release the pressure, and it can be locked from all controls. The table is lightweight and easy to move, and its clear structure supports hygiene. A digital control unit notifies when maintenance is required, and remote support allows assistance to be provided quickly.
Key benefits
What makes 4040X different.
Exceptionally wide height range, 40–95 cm
An ergonomic working height for the clinician and a low access height for the patient.
Easy to get onto
The low minimum height means both children and elderly patients can get onto the table easily, with an optional lift support for further assistance.
Safety that reacts
The table detects a pinching situation, stops and raises to release the pressure, and can be locked from all controls.
Hands-free operation and a clear structure
The optional hands-free foot control adjusts height and back section separately from either side, and the open frame supports a high level of hygiene.
Maintenance notified in advance
The digital control unit signals when maintenance is due, and remote support gets help to the customer quickly.
Key features
- Two-section table top
- Height adjustment range 40–95 cm
- Back section adjustment, 73°
- Automatic stop and lift when movement is obstructed
- Table can be locked from all controls
- Patient surface 200 cm long and 70 cm wide, 80 and 90 cm as options, 4040XH model: optional 80cm width
- Safe working load 225 kg
- Ø 125 mm individually lockable castors
- Maximum of six mounting positions for the IV-pole
- Accessory rail 380 × 10 × 25 mm, up to six units
- 5 cm upholstery, 7 cm as an option, in several materials and colours
- Digital control unit with maintenance notification and remote support
Models / Configurations
Two models share the same frame, footprint, table top and accessory platform. They differ in how height, back section and Trendelenburg are adjusted.
• 4040X — electric height adjustment, with hand control, foot control or a hands-free foot control depending on configuration. Trendelenburg is available as a manual or electric option.
• 4040XH — hydraulic height adjustment operated by a foot pedal; back section and Trendelenburg positions adjusted with gas spring assistance. Patient surface width option 80 cm.
Technical specifications
| Specification | Value |
|---|---|
| Total width | 75 cm (80 / 90 cm optional). 4040XH: optional 80 cm |
| Patient surface width | 70 cm (80 / 90 cm optional). 4040XH: optional 80 cm |
| Total length | 200 cm |
| Patient surface length | 200 cm |
| Total weight | 108 kg |
| Height adjustment range | 40–95 cm with Ø 125 mm castors; depends on castor size and product model |
| Back section length | 70 cm |
| Back section adjustment | 73° |
| Electric Trendelenburg / anti-Trendelenburg | 20° (optional) |
| Manual Trendelenburg | 12° (optional) |
| Castors | Ø 125 mm, individually lockable |
| Castors (optional) | Centrally lockable Ø 125 / 150 mm twin castors |
| Other features | Maximum of six mounting positions for the IV-pole; table can be locked from all controls; automatic stop and lift when movement is obstructed |
| Upholstery | 5 cm, or 7 cm as an option. Several materials and color options |
| Safe working load (SWL) | 225 kg |
| CE marking | Yes. CE-marked medical device, MDR 2017/745 class 1 |
| Warranty | 2 years |
| Country of manufacture | Finland |
| Manufacturer | Lojer Oy, Putajantie 42, 38210 Sastamala, Finland |
Options and accessories
Factory-installed option
- Hand control
- Hands-free foot control for height and back section
- Single- or two-part foot control
- Manual Trendelenburg
- Electric Trendelenburg and anti-Trendelenburg, including battery
- Battery (emergency use)
- Centrally lockable 125 / 150 mm twin castors
- Facehole
- Manual emergency lowering of the back section
Accessories
- Side rail
- IV-pole
- Arm support
- Neck cushion
- Examination light
- Push handles
- Adapter for accessories
- Accessory rail 380 × 10 × 25 mm (max. 6 units); all accessories fitted to the accessory rail fixing
- Anaesthesia frame
- Lift support
- Collision bumper set
- Paper roll stand and cutter
Service & lifestyle
The 4040X carries a two-year warranty and is manufactured in Finland by Lojer Oy under ISO 9001, ISO 13485 and ISO 14001. The digital control unit notifies when maintenance is required, and remote support allows assistance to be provided quickly. Lojer Medical Service provides maintenance, repairs and spare parts, and Lojer Care contracts range from preventive maintenance to an end-to-end service including spare parts and travel.
